ADAST 8992.6x2/LPG

ADAST 8992.6x2/LPG
Call to order

- Modern and compact design

- The high-tech hydraulic system of dispenser

- The high-tech flow meter with integrated intelligent pulse meter with electronic gauging

- New electronic control unit ADP/T with one-chip microcontroller for controlling all functions of fuel dispenser.

- Automatic Temperature Compensation system

- High-quality durable materials with low maintenance requirements

- Ergonomic placing of LPG nozzle

- New design of pre-selection keyboard

- Optionally supplied with ADAMAT nozzles.


Details:

Pump power – 30-40 l/min

Single-side construction –optional

Locking – LPG dispenser and nozzle coating

Temperature range - default from -20 to +50 °C, optional from -30 to +60 °C

Power supply: 220 V AC ±15 %, 50 Hz

Hydraulic supply: 30-40 l/min depending on dispenser type, pumping unit and piping.

Supplied with:

LPG hoses
LPG nozzles
Safety and discontinuous couplings

Two-step solenoid valve
Volume/cost selection unit
Electromechanical totalizing counter
ATC system
Dead man button
Staff call button

Stop button
Signaling lights
Cabinet heating with thermostat

Power supply breaker
ADAMAT nozzle
ADP1/T counter
IFSF – LON – FTT-10 or TCP/IP
– Ethernet interface

Technical Specifications:

Quantity of products

2

Quantity of nozzles

4

Operating pressure (max) (MPa)

1,8

Operating pressure (min) (MPa)

0,7

Output accuracy (%)

±0,5

Length (mm)

950

Width (mm)

410

Height (mm)

1600

Hose length (m)

from 4 to 7
